Why compromise safety or performance!

Aviomania Aircraft is the largest ultralight aircraft manufacturer in Cyprus. The founder of Aviomania Aircraft, Nicolas Karaolides, has been involved in Aviation since 1983. He has always been involved in flying, maintaining, designing and building aircraft. He holds licences and degrees in aircraft engineering, electronics and flying. Due to his experience and advanced understanding of gyroplane aerodynamics, Aviomania Aircraft offers some of the best and safest gyroplanes available today. Not only are our gyroplanes some of the safest and most stable gyroplanes in the world but they are also some of the most maneuverable and high performance aircraft in their class.

For example, our open frame single seat gyroplane has a maximum sustained straight and level airspeed of 165 Kph (90 Kt., 105 Mph) and sustained climb of 900 fpm with only 65 HP!

A performance that is similar to, if not better than, other open frame gyroplanes with 100 HP or more!

Our effort and dedication is focused on designing, developing and manufacturing gyroplanes that offer the best performance and safety. Our gyroplanes (Genesis solo, Genesis CE, Genesis Sport and Genesis Duo) have worldwide recognition thanks to the “no compromise” design philosophy. Integrating new safety systems with state-of-the-art gyroplane airframe & rotor design in an attractive body design is what gives the “Genesis” line its outstanding safety and performance. The range of Genesis gyroplanes are probably the only European manufactured gyroplanes that incorporate all the aerodynamic safety mechanics that enable safety even at the extreme edges of the gyroplane flight envelope.

Aviomania’s tail design offers the best possible engine torque compensation and frame stability. Most other manufacturers use a vertical tail that is covered by the lower half of the propeller diameter and a horizontal stabiliser placed low on the keel. Although this design is good for reducing PIO (pilot induced oscillation), it does not offer ANY torque or power push over compensation. It also requires constant rudder correction with power changes especially during take-off and landing. Aviomania’s ATD design has the vertical tail covered by 75% of the propeller diameter and with the horizontal stabiliser positioned 60% in the prop wash and 40% in free air, most engine torque and yaw tendencies are eliminated.

No need for “rudder dancing” by the pilot during takeoff, landing or power changes. The ATD works even in very low G situations, at high or low speed and at high or low power settings. The frame flies straight and is not affected by power changes making the “Genesis” gyroplanes some of the easiest and most forgiving to fly, take-off and land. A lot of accidents have occurred during take-off, landing, and low G situations; our ATD design greatly reduces the chance of such accidents occurring. We strongly feel that this design will soon be the standard.

A CLT design is offered as standard with all of our “Genesis” gyroplanes. Aviomania is the only European manufacturer that offers CLT gyroplanes. Why is CLT better? Physics, in simple terms, state that all forces are applied to a body in relation to its center of mass (CM). In other words, if the propeller is pushing / pulling an aircraft above its center of mass (the case with most gyroplanes available today) the aircraft will want to nose over. To correct this we need to apply another force to reduce the imbalance. Most manufacturers are “correcting” the High Trust Line (HTL) by having a very heavy rotor and vectoring the rotor thrust (Lift) ahead of the center of gravity in order to pull the nose up against the engine pushing the nose down. This “solution” makes the gyroplane unstable. A stable aircraft has its lift passing slightly aft (behind) the Center of Gravity (CG). Also this “solution” does not offer good thrust offset compensation at reduced Gs because the rotor thrust that is used to “keep” the nose up when reduced cannot compensate for the engine’s power offset that is pushing the nose down.

Another “solution” is by aerodynamically downloading the horizontal stabiliser which adds “artificial” weight on the gyroplane, reducing its performance and maneuverability, but this “solution” works only at higher airspeeds. Some other manufacturers choose to do nothing to compensate for the thrust offset, which makes their gyroplanes unstable, power change sensitive and dangerous in reduced G situations.

A CLT gyroplane has the engine thrust passing through, or very near its CG, therefore engine power will have no effect on pitch stability, increasing the performance, stability and safety.

Aviomania uses a triangulated modular bolted frame design, offered as standard with all of our “Genesis” gyroplanes.

Aviomania uses aviation grade aluminium bolt together construction, using AN (aviation grade) bolts. This construction method has been used in gyroplane construction for many decades and has proved to be very reliable, strong, service and crack free as well as corrosion resistant.

Most Gyroplanes have a single tube or 2 tubes welded on top to each other in front of the mast to support the pilot and nose wheel.

The “Genesis” uses a triangulated construction (3 tubes forming a pyramid). This is light but offers the best pilot protection in the event of an accident.

It is far superior to the single metal tube (or 2 stacked on top of each other) that is commonly used on other gyroplanes.

Also the bolted frame can be easily repaired compared to the welded construction that needs the complete frame to be replaced. Only damaged parts need be replaced.

Our Fuel tank is made using fuel resistant resin and Aramid (Kevlar) / Glass fabrics making for a strong but light construction that resists impact and piercing. Our Kevlar reinforced fuel tank is positioned in a protected area within our light, but very strong triangulated airframe offering the best possible pilot protection.

Our landing gear is made from 4130 Chrome-moly alloy (aviation grade) which is very strong and light. The wide track offers exceptional stability. Our own developed soft coupled castoring (SCC) nose wheel offers a narrow turn radius at low speeds and minimises nose wheel turn angles at high speeds offering excellent back tracking capabilities as well as directional stability, straight tracking and increased safety during landings by minimising the risk of tip over.
